Baru kemarin saya posting CadSoft Eagle Professional 6.0 Multilingual Full sekarang keluar versi barunya menjadi CadSoft Eagle Professional 6.3 Multilingual Full. CadSoft Eagle Professional 6.3 Multilingual Full merupakan software untuk mendesain PCB
yang menawarkan fungsionalitas tingkat tinggi dengan menawarkan tiga modul: Skema-Editor, Editor Layout dan autorouter yang tertanam pada satu antarmuka tunggal. CadSoft Eagle Professional 6.3 Multilingual Full ini sangat mudah digunakan, tak heran jika banyak pengguna memakai software ini sejak 20 tahun terakhir ini, dan memungkinkan fitur tambahan, seperti simulasi, 3D-visualisasi, impor dan ekspor data. Bagi kamu yang hoby mendesain PCB untuk elektronik silahkan download filenya di bawah tapi sebelum itu lihat dulu beberapa fitur dibawah.
Schematic Editor
# Up to 999 sheets per schematic
# Icon preview for sheets
# Sorting sheets with Drag&Drop
# Cross references for nets
# Automatic generation of contact cross references
# Simple copying of parts
# Replace function for parts without loss of consistency between schematic and layout
# Online Forward&Back Annotation between schematic and board
# Automatic generation of supply connections
# Automatic board generation
# Electrical Rule Check (error check in the Schematic and consistency check between Schematic and Layout)
# User Defined Net Classes for Via Size Wire Width and Clearance
Layout Editor
# 4 x 4m (about 150 x 150 inch)
# Full SMD support
# Support of Blind and Buried vias
# Rotation of objects in arbitrary angles (0.1degree steps)
# Components can be locked against moving
# Texts can be placed in any orientation
# Dynamic calculation of signal lines while routing the layout
# Magnetic pads function
# Tracks can be drawn with rounded corners in any radius
# Mitering to smooth wire joints
# Design Rule Check for board layouts (checks e.g. overlaps measures of pads or tracks)
# Copper pouring (ground plains)
# Package variants support
# Differential pair routing
# Meander command for length compensation of signals
# Support of assembly variants
# User definable free programmable User Language to generate data for mounting machines test equipments milling machines or any other data format
# Output of manufacturing data for pen plotters photo plotters and drilling machines with the CAM Processor
Autorouter
# Fully integrated into basic program
# Routing grid down to 0.02 mm (about 0.8 mil)
# Basic engine for the Follow-me-router a tool that supports you in manual routing; the trace of a selected signal will be calculated automatically
# Ripup&Retry algorithm
# User definable strategy by cost factors
# No placement restrictions
# Uses the layout’s Design Rules
# Change between manual and automatic routing at any time
# Up to 16 signal layers (with user definable preferred directions)
# Full support of Blind and Buried vias
# Takes into consideration various net classes
